Light Source

• Philips MSR Platinum 35 lamp, PGJX36, 55,000 lumens, 7800 K, CRI >75, 750H

• Electronic ballast, dichroic glass reflector for maximum light output

• Mechanical dimmer, Hotspot function (adjustable beam distribution) controllable from the console

• Console-controlled on/off, quiet fan



Movement

• Fast and silent automatic repositioning, pan: 540°

Tilt: 270°, 8 or 16 bits, lock for storage on pan and tilt

Colors

• CMY color printing (Cyan, Magenta, Yellow) + Variable CTO + 7-color wheel



Gobos

• 2 rotating and indexable 7-gobo wheels (8 or 16 bits) made of glass on a Slot & Lock mount (26.8 mm outer diameter, 22 mm image diameter, 1.1 mm to 4 mm thickness)



Effects

• Dual animation wheel for exclusive and sensational effects

• Fast and silent iris, pulse effect from 3 Hz

• Indexable and rotating 5-facet prism with variable speed

• Mechanical and electronic strobe, with ZAP effect



Focus

• Motorized and controllable autofocus console

Zoom

• Motorized linear from 8.5° to 46.5°

Frost

• Motorized linear



Control / Settings

• Via DMX (29, 31, or 38 channels), RNS2, RDM, ArtNet (ACN ready),

MA Net, MA Net2

• Backlit color LCD touchscreen equipped with the “RNS 2” (Robe Navigation System) with battery for control and settings when powered off

• 3 programs of 100 steps each, storable via the control panel

• Integrated machine diagnostics for easy maintenance



Option

• Wireless control via LUMEN CRMX RADIO Power Supply / Consumption • 100–240 V, 50–60 Hz • 1100 VA Weight / Dimensions • 21.7 kg • 722 (head upright) x 446 x 530 mm Operating Temperature • Ambient 45°C max, Surface 100°C max Connectivity • XLR 5 and 3, ETHERCON RJ45 Hanging • 2 quarter-turn Omega connectors included
